Industrial Axial Fans & Blowers
High-performance axial fans for efficient, high-volume airflow.
AIRPRO // PRODUCTS
Powerful Industrial Axial Fans for High-Volume Ventilation
AirPro’s industrial axial fans deliver reliable, high-volume airflow with efficient performance, making them a practical solution for a wide range of industrial ventilation and process air applications.
Engineered to move large volumes of air at low to moderate static pressures, axial fans are ideal for general ventilation, cooling, exhaust, and air exchange in demanding industrial environments. Their compact, inline design allows for efficient airflow in applications where space, airflow volume, and system simplicity are key considerations.
Industrial Axial Fan Overview
AirPro’s industrial axial fan technology is built to provide dependable, high-volume airflow across a range of industrial applications. Designed for efficient air movement and durable operation, axial fans are well suited for ventilation, cooling, exhaust, and other applications requiring large air volumes with lower pressure demands.
Selecting the right axial fan depends on your required airflow, static pressure, operating environment, and installation constraints. Our experienced application engineers are here to help you identify the best solution for your system and performance goals.
Built with heavy-duty, industrial-grade construction, AirPro axial fans are designed to perform in demanding conditions. Customers rely on AirPro for durable, efficient, and application-specific airflow solutions that help keep operations running smoothly.
Industrial Axial Fan Performance & Design
- Volume: up to 250,000 cfm
- Pressure: up to 12”wg
- Temperature: 100°F standard (up to 150°F with factory approval)
- Static Efficiency: 65.4%
- Drive: Belt and direct
AirPro designs and builds both standard and custom industrial fans with an unsurpassed level of quality and service. All of our products are also backed by our industry-leading 3-year warranty.
Axial Fan Types
AB7E
Axial, Belt-Drive, 7-Blades, E-Hub
Pairs belt drive flexibility with the E hub’s larger blade-to-housing ratio. The E hub’s greater blade exposure allows it to process slightly more volume for a given size and speed, making it a strong choice when maximum airflow capacity is a priority.
Belt drive allows motor placement outside the airstream, which is advantageous for elevated temperature applications (up to 150°F with factory consult).
- Arrangement 4; E hub for higher airflow capacity
- 26,500 fpm max tip speed
AB7K
Axial, Belt-Drive, 7-Blades, K-Hub
Combines belt drive with the K hub configuration. The K hub’s larger hub diameter relative to housing means less blade length, but allows a higher tip speed making this model suited for applications where rotational speed is critical to meeting performance targets.
The K hub carries slightly more mass than the E for a given frame size.
- Arrangement 9; K hub for higher tip speed
- 28,500 fpm max tip speed
AD7E
Axial, Direct-Drive, 7-Blades, E-Hub
Delivers direct drive simplicity with the E hub configuration in a compact, low-maintenance design.
With no belts, drive components, or intermediate shaft to maintain, the motor resides within the airstream, making it a strong choice for clean-air applications at standard temperatures (up to 100°F).
- Arrangement 4; E hub for higher airflow capacity
- 26,500 fpm max tip spped
AD7K
Axial, Direct-Drive, 7-Blades, K-Hub
Delivers direct drive simplicity with the higher tip speed capability of the K hub. For applications where a more compact unit without belt maintenance is desired and the K hub’s speed advantage is beneficial, it provides an efficient, low-maintenance solution.
As with all Arrangement 4 models, air-cooled motor treatment is standard to protect motor longevity in the airstream.
- Arrangement 4; K hub designed for higher tip speed
- 28,500 fpm max tip speed
Applications
Common Axial Fan Applications
Induced Draft
Used in select induced draft applications where high airflow, compact design, and performance are key.
Food Product Drying
Well-suited for food drying systems that need consistent, high-volume airflow and dependable process control.
Drying Systems
A strong choice for industrial drying systems that depend on efficient, uniform airflow throughout the process.
